acc. to ISO 228/1 F/F female thread, body made of stainless steel (1.4408)(CF8M), ball made of stainless steel (1.4408)(CF8M), seal ball made of PTFE, medium temp -20°C to +180°C, max. operating pressure 40 bar Operating pressure 40 bar
3-way ball valve 1/2 inch made of brassType T bore, internal thread (BSP) acc. to ISO 228-1 F-F-F, body made of brass-nickel plated, ball made of brass-chrome plated, ball seal PTFE, stem seal PTFE, medium temp. (min./max.) -20°C to +150°C, Max. Operating pressure: 25 bar with single-acting pneumatic actuator, normally closed.
Internal thread ball valve 1/2 inch acc. to ASME B1.20.1 NPT, Body made of stainless steel (1.4408)(CF8M), Ball made of stainless steel (1.4408)(CF8M), chrome plated, Seal ball made of PTFE+15% G.F, Max. Operating pressure 63 bar
3-way ball valve 1/2 inch made of brassType L bore, internal thread (BSP) acc. to ISO 228-1 F-F-F, body made of brass, nickel plated, ball made of brass, chrome plated, seal ball PTFE, stem seal PTFE, medium temp. (min./max.) -20°C up to +150°C, max. Operating pressure: 25 bar with double-acting pneumatic actuato.
Brass ball valve 1/2 inch with pneumatic actuatorConnection according to ISO 7/1 F-F, Flange plate according to ISO 5211, Body & Ball made of Brass CW617N, Ball seal: PTFE + FKM, Temperature range: -15°C to +90°C, 2-way- full bore - 2-piece, Peaks up to +120°C for 1 hour only in open or closed position, Max. Operating pressure: 25 bar, Approval: WRAS, Actuation: Pneumatic actuator Single acting, SPRING FORCE CLOSING 90° swivelling
Ball valve 1/2 inch female threadfemale thread acc. to ISO 7/1 Rp (F-F), Ball brass chrome-plated, Seal ball PTFE, O-ring Viton/NBR, Housing brass nickel-plated for liquid and gaseous media, DVGW Gas Max. Operating pressure 50 bar
3-way ball valve 1/2 inch made of brassType T bore, internal thread (BSP) acc. to ISO 228-1 F-F-F, body made of brass-nickel plated, ball made of brass-chrome plated, ball seal PTFE, stem seal PTFE, medium temp. (min./max.) -20°C to +150°C, max. operating pressure: 25 bar, operation hand lever.
Electric actuated ball valve 1/2 inch female thread Acc. to ISO 7-1 F-F, body / ball CW617N, sealing ball PTFE +FKM, max. pressure 25 bar, WRAS approved with electric actuator(J4C S20), running time(90°) 9s ± 10%, multi voltage system 24V - 230V - 240V AC/DC
3-way ball valve 1/2 inch made of brassType T bore, internal thread (BSP) acc. to ISO 228-1 F-F-F, body made of brass-nickel plated, ball made of brass-chrome plated, ball seal PTFE, stem seal PTFE, medium temp. (min./max.) -20°C up to +150°C, max. Operating pressure: 25 bar with double-acting pneumatic actuator.
Stainless steel weld end ball valve 1/2 in. acc. to ANSI B 16.25, body & ball stainless steel CF8M (1.4408), gasket TFM 1600,full bore, 3 pieces, Approval TA-Luft, ATEX, AD2000-A4 with hand lever
3-way ball valve 1/2 inch brass Type L bore, internal thread (BSP) acc. to ISO 228-1 F-F-F, body brass-nickel plated, ball brass-chrome plated, ball seal PTFE, stem seal PTFE, medium temp. -20°C to +150°C, max. operating pressure 25 bar. Max. operating pressure 25 bar, Actuation: electric (J4C S20) rotary actuator, Running time(90°) 9s ± 10%, 24V - 230V - 240V AC/DC 50/60HZ
3-piece Internal thread ball valve 1/2 inch stainless steel, Connection acc. to ISO 7-1 (EN 10226-1) F-F, Body / ball / shaft stainless steel (SS316)(CF8M), Seal ball PTFE + 15% glass fibre, Shaft seal PTFE + graphite, Full bore ,Max. Operating pressure 63 bar
Stainless steel ball valve 1/2" PN 63 female thread acc. to ISO 7-1(EN 10226-1) F-F, Body / ball / shaft made of stainless steel (SS316)(CF8M), Seal made of ball PTFE + 15% glass fibre, Full bore , 2 pieces Max. Operating pressure 63 bar with single-acting pneumatic actuator
